Embraer E190 Cockpit Poster

Learn the cockpit layout of the Embraer E190 with this pilot training poster

× Close Request a Demo

Embraer E190 Cockpit Poster

Aircraft Cockpit Poster

Overview

The Embraer E190 Poster was drawn with a focus on both photo-realism and instructional value, allowing you to familiarize yourself with the E190 cockpit before ever stepping foot inside one! This cockpit training poster features full color vector illustrations drawn using photos and general measurements from an Embraer E190 cockpit, so that it provides an accurate representation of colors and dimensions, as well as a detailed portrayal of the individual controls and indicators. The E190 Cockpit Poster includes the flight instruments, the center pedestal, and the overhead panel. Designed for pilots transitioning to the E190, this poster provides excellent supplemental reference during ground school training, including the ability to practice cockpit flows.

See Avsoft’s Embraer 190 Aircraft Systems Course

Product Images

Options

Standard
Three 17" x 36" (43.2 cm x 91.4 cm) sheets of paper

Each cockpit panel is printed on an individual sheet. Cockpit panels are not printed at the same scale, they are each sized to maximum print area on each sheet. Referred to as "standard" or "student" size, this is our most popular poster option.

Life Size
Life-sized/100% scale/ 1:1

Each cockpit panel is printed at 100% scale/1:1 on an individual sheet of paper. These poster sets are designed for training purposes, not to be used as design templates.
